详细介绍mysql 协议的错误包及解析

git

https://github.com/sea-boat/mysql-protocol

概况

mysql客户端与mysql服务端交互过程中，如果服务端遇到错误需要告知客户端则返回错误包。

mysql通信报文结构

错误包

Payload

更多详情 ： http://dev.mysql.com/doc/internals/en/packet-ERR_Packet.html

错误包操作

错误包类

/**
 *
 * @author seaboat
 * @date 2016-09-25
 * @version 1.0
 * <pre class="brush:php;toolbar:false;"><b>email: </b>849586227@qq.com

<b>blog: </b>http://www.php.cn/;/pre>
 * <p>mysql error packet.</p><div class="aritcle_card flexRow">
                                                        <div class="artcardd flexRow">
                                                                <a class="aritcle_card_img" href="/xiazai/learn/2594" title="自学 PHP、MySQL和Apache"><img
                                                                                src="https://www.herecours.com/d/file/efpub/2026/28-28/20260228084146681487.jpg" alt="自学 PHP、MySQL和Apache"  onerror="this.onerror='';this.src='/static/lhimages/moren/morentu.png'" ></a>
                                                                <div class="aritcle_card_info flexColumn">
                                                                        <a href="/xiazai/learn/2594" title="自学 PHP、MySQL和Apache">自学 PHP、MySQL和Apache</a>
                                                                        <p>本书将PHP开发与MySQL应用相结合，分别对PHP和MySQL做了深入浅出的分析，不仅介绍PHP和MySQL的一般概念，而且对PHP和MySQL的Web应用做了较全面的阐述，并包括几个经典且实用的例子。
本书是第4版，经过了全面的更新、重写和扩展，包括PHP5.3最新改进的特性（例如，更好的错误和异常处理），MySQL的存储过程和存储引擎，Ajax技术与Web2.0以及Web应用需要注意的安全</p>
                                                                </div>
                                                                <a href="/xiazai/learn/2594" title="自学 PHP、MySQL和Apache" class="aritcle_card_btn flexRow flexcenter"><b></b><span>下载</span> </a>
                                                        </div>
                                                </div>
 */public class ErrorPacket extends MySQLPacket {
    public static final byte header = (byte) 0xff;
    private static final byte SQLSTATE_MARKER = (byte) '#';
    private static final byte[] DEFAULT_SQLSTATE = "HY000".getBytes();
    public int errno;
    public byte mark = SQLSTATE_MARKER;
    public byte[] sqlState = DEFAULT_SQLSTATE;
    public byte[] message;
    public void read(byte[] data) {
        MySQLMessage mm = new MySQLMessage(data);
        packetLength = mm.readUB3();
        packetId = mm.read();
        mm.read();
        errno = mm.readUB2();
        if (mm.hasRemaining() && (mm.read(mm.position()) == SQLSTATE_MARKER)) {
            mm.read();
            sqlState = mm.readBytes(5);
        }
        message = mm.readBytes();
    }
    public void write(ByteBuffer buffer) {
    int size = calcPacketSize();
        BufferUtil.writeUB3(buffer, size);
        buffer.put(packetId);
        buffer.put(header);
        BufferUtil.writeUB2(buffer, errno);
        buffer.put(mark);
        buffer.put(sqlState);
        buffer.put(message);
    }    @Override
    public int calcPacketSize() {
    int size = 9;// 1 + 2 + 1 + 5
        if (message != null) {
            size += message.length;
        }
        return size;
    }
    @Override
    protected String getPacketInfo() {
    return "MySQL Error Packet";
    }
}

十六进制转换工具

/**
 *
 * @author seaboat
 * @date 2016-09-25
 * @version 1.0
 * <pre class="brush:php;toolbar:false;"><b>email: </b>849586227@qq.com

<b>blog: </b>http://www.php.cn/;/pre>
 * <p>hex transform util.</p>
 */public class HexUtil {
    private final static byte[] hex = "0123456789ABCDEF".getBytes();
    public static String Bytes2HexString(byte[] b) {
    byte[] buff = new byte[2 * b.length];
    for (int i = 0; i < b.length; i++) {
            buff[2 * i] = hex[(b[i] >> 4) & 0x0f];
            buff[2 * i + 1] = hex[b[i] & 0x0f];
        }        return new String(buff);
    }    public static String str2HexStr(String str) {
    char[] chars = "0123456789ABCDEF".toCharArray();
        StringBuilder sb = new StringBuilder("");
        byte[] bs = str.getBytes();
        int bit;
        for (int i = 0; i < bs.length; i++) {
            bit = (bs[i] & 0x0f0) >> 4;
            sb.append(chars[bit]);
            bit = bs[i] & 0x0f;
            sb.append(chars[bit]);
        }        return sb.toString();
    }
}

错误包生成测试

/**
 *
 * @author seaboat
 * @date 2016-09-25
 * @version 1.0
 * <pre class="brush:php;toolbar:false;"><b>email: </b>849586227@qq.com

<b>blog: </b>http://www.php.cn/;/pre>
 * <p>test auth packet.</p>
 */public class ErrorPacketTest {
    @Test
    public void produce() {
        ErrorPacket err = new ErrorPacket();
        err.packetId = 1;
        err.errno = 32322;
        err.message = "sorry".getBytes();
        ByteBuffer buffer = ByteBuffer.allocate(256);
        err.write(buffer);
        buffer.flip();        byte[] bytes = new byte[buffer.remaining()];
        buffer.get(bytes, 0, bytes.length);
        String result = HexUtil.Bytes2HexString(bytes);
        System.out.println(result);
        assertTrue(Integer.valueOf(result.substring(0, 2), 16) == result
                .length() / 2 - 4);
        ErrorPacket err2 = new ErrorPacket();
        err2.read(bytes);
        assertTrue(err2.errno == 32322);
        assertTrue(err2.message.length == "sorry".getBytes().length);
    }
}

 以上就是详细介绍mysql 协议的错误包及解析的内容，更多相关内容请关注PHP中文网（www.php.cn）！
