mysql复制+keepalived+haproxy配置（负载均衡）

mysql+keepalived+haproxy配置（负载均衡） 实验系统：CentOS 6.5_x86_64 实验前提：防火墙和selinux都关闭 实验软件：keepalived-1.2.13　　haproxy-1.8.13　　mysql—5.7.21 主1 ip：192.168.226.134 主2 ip：192.168.226.135 vip     192.168.226.150 一、安装mysql 获取mysql安装包：wget https://dev.mysql.com/get/Downloads/MySQL-5.7/mysql-5.7.21-linux-glibc2.12-x86_64.tar.gz 安装mysql过程省略 二、配置mysql复制 命令  service iptables stop  检查：service iptables status 关闭vi /etc/selinux/config  SELINUX=disabled 两台服务器上都要执行： 创建复制用户 grant replication slave on *.* to 'repl'@'%' identified by '123'; 进入从服务器mysql 命令： # mysql -uroot -p 关闭slave 命令：stop slave; 开始配置： 输入下面代码即可： CHANGE MASTER TO MASTER_HOST='192.168.226.135', MASTER_USER='repl', MASTER_PASSWORD='123', MASTER_LOG_FILE='mysql-bin.000002', MASTER_LOG_POS=681; 先在从服务器配置完成，启动从服务器： 命令： start slave; 反向再配置一次 三、安装haproxy（两台节点都要安装） tar -zxvxf haproxy-1.8.13.tar.gz  cd haproxy-1.8.13 make TARGET=linux2628       //根据自己主机设定 make install  提供启动脚本 vi /etc/init.d/haproxy #!/bin/sh # # haproxy # # chkconfig:   - 85 15 # description:  HAProxy is a free, very fast and reliable solution \ #               offering high availability, load balancing, and \ #               proxying for TCP and  HTTP-based applications # processname: haproxy # config:      /etc/haproxy/haproxy.cfg # pidfile:     /var/run/haproxy.pid # Source function library. . /etc/rc.d/init.d/functions # Source networking configuration. . /etc/sysconfig/network # Check that networking is up. [ "$NETWORKING" = "no" ] && exit 0 exec="/usr/local/sbin/haproxy" prog=$(basename $exec) [ -e /etc/sysconfig/$prog ] && . /etc/sysconfig/$prog cfgfile=/etc/haproxy/haproxy.cfg pidfile=/var/run/haproxy.pid lockfile=/var/lock/subsys/haproxy check() {     $exec -c -V -f $cfgfile $OPTIONS } start() {     $exec -c -q -f $cfgfile $OPTIONS     if [ $? -ne 0 ]; then         echo "Errors in configuration file, check with $prog check."         return 1     fi     echo -n $"Starting $prog: "     # start it up here, usually something like "daemon $exec"     daemon $exec -D -f $cfgfile -p $pidfile $OPTIONS     retval=$?     echo     [ $retval -eq 0 ] && touch $lockfile     return $retval } stop() {     echo -n $"Stopping $prog: "     # stop it here, often "killproc $prog"     killproc $prog     retval=$?     echo     [ $retval -eq 0 ] && rm -f $lockfile     return $retval } restart() {     $exec -c -q -f $cfgfile $OPTIONS     if [ $? -ne 0 ]; then         echo "Errors in configuration file, check with $prog check."         return 1     fi     stop     start } reload() {     $exec -c -q -f $cfgfile $OPTIONS     if [ $? -ne 0 ]; then         echo "Errors in configuration file, check with $prog check."         return 1     fi     echo -n $"Reloading $prog: "     $exec -D -f $cfgfile -p $pidfile $OPTIONS -sf $(cat $pidfile)     retval=$?     echo     return $retval } force_reload() {     restart } fdr_status() {     status $prog } case "$1" in     start|stop|restart|reload)         $1         ;;     force-reload)         force_reload         ;;     check)         check         ;;     status)         fdr_status         ;;     condrestart|try-restart)         [ ! -f $lockfile ] || restart         ;;     *)         echo $"Usage: $0 {start|stop|status|restart|try-restart|reload|force-reload}"         exit 2 esac chkconfig --add haproxy chkconfig haproxy on chmod +x /etc/init.d/haproxy 提供配置文件 mkdir /etc/haproxy mkdir /var/lib/haproxy useradd -r haproxy vi /etc/haproxy/haproxy.cfg global     log         127.0.0.1 local2     chroot      /var/lib/haproxy     pidfile     /var/run/haproxy.pid     maxconn     4000     user        haproxy     group       haproxy     daemon     stats socket /var/lib/haproxy/stats defaults     mode                    tcp                 log                     global     option                  dontlognull     option                  redispatch     retries                 3     timeout http-request    10s     timeout queue           1m     timeout connect         10s     timeout client          1m     timeout server          1m     timeout http-keep-alive 10s     timeout check           10s     maxconn                 600            listen stats                                   mode http     bind :6677                                 stats enable     stats hide-version                         stats uri     /haproxyadmin?stats          stats realm   Haproxy\ Statistics          stats auth    admin:admin                  stats admin if TRUE                   frontend  main      bind *:80                          default_backend             mysql        backend mysql     balance     leastconn                      server m1 192.168.226.134:80 check port 80 maxconn 300     server m2 192.168.226.135:80 check port 80 maxconn 300 启动日志： vi /etc/rsyslog.conf  # Provides UDP syslog reception                 $ModLoad imudp $UDPServerRun 514 local2.*             /var/log/haproxy.log       service rsyslog restart 启动测试haproxy： service haproxy start netstat -tnlp 四、安装keepalived （两台服务器都要执行） yum install -y keepalived chkconfig --add keepalived chkconfig keepalived on mv /etc/keepalived/keepalived.conf /etc/keepalived/keepalived.conf.bak vi /etc/keepalived/keepalived.conf ! Configuration File for keepalived global_defs {    router_id Mysql_ha } vrrp_script chk_mysql {    script "/etc/keepalived/check_mysql.sh"    interval 2    weight 5 } vrrp_script chk_haproxy {    script "/etc/keepalived/chk.sh"    interval 2    weight 5 } vrrp_instance mysql-instance {    state MASTER   #另一台为BACKUP    interface enp4s0  #与网卡名称对应    virtual_router_id 11 #每一个IP唯一，另一台绑定相同IP要与整个ID一致    priority 10   #另一台为9    advert_int 1    authentication {         auth_type PASS         auth_pass password321    }    track_script {        chk_mysql    }    virtual_ipaddress {    192.168.226.150/24    } } vrrp_instance mysql-ha {    state MASTER    interface enp4s0    virtual_router_id 13    priority 10 advert_int 1    # nopreempt    authentication {         auth_type PASS         auth_pass password321    }    track_script {        chk_haproxy    }    virtual_ipaddress {    192.168.226.14/24    }     notify_backup "/etc/init.d/haproxy restart"     notify_fault "/etc/init.d/haproxy stop" } 五、在两台机器上测试 在浏览器打开http://192.168.226.150:6677/haproxyadmin?stats，打开haproxy状态页：
