--- 官方版本测试到8.0.21依旧存在这个问题，Percona已经修复了，修复如下 https://www.percona.com/blog/2018/03/27/analyze-table-is-no-longer-a-blocking-operation/ 能力有限简单记录。 --- 公众号 MySQL学习 ###一、问题描述 问题如下： ``` mysql> show processlist; +----+-----------------+-----------+------+---------+-------+-------------------------+----------------------------------+ | Id | User | Host | db | Command | Time | State | Info | +----+-----------------+-----------+------+---------+-------+-------------------------+----------------------------------+ | 5 | event_scheduler | localhost | NULL | Daemon | 34025 | Waiting on empty queue | NULL | | 11 | root | localhost | NULL | Query | 1528 | User sleep | select sleep(1000) from test.e01 | | 12 | root | localhost | NULL | Query | 0 | starting | show processlist | | 23 | root | localhost | NULL | Query | 33 | Waiting for table flush | select * from test.e01 | | 24 | root | localhost | NULL | Query | 7 | Waiting for table flush | select * from test.e01 | +----+-----------------+-----------+------+---------+-------+-------------------------+----------------------------------+ ``` 乍一看来，很是奇怪，这里没有出现我们经常遇到的flush table/flush table with read lock 堵塞，直接出现了 Waiting for table flush的堵塞，有点像 https://www.jianshu.com/p/b141585cd844 以前记录的文章中的案例2，但是其实并不一样，这里是由于analyze table语句造成的。构造非常简单（必须是社区版本，我使用的8.0.21），如下： ``` 窗口1： mysql> select sleep(1000) from test.e01;（要有几条数据） 这条语句肯定结束不了 窗口2： mysql> analyze table test.e01 -> ; +----------+---------+----------+----------+ | Table | Op | Msg_type | Msg_text | +----------+---------+----------+----------+ | test.e01 | analyze | status | OK | +----------+---------+----------+----------+ 窗口3： mysql> select * from test.e01; 堵塞 ``` 此时堵塞的情形就是Waiting for table flush ###二、analyze触发了什么 analyze table 除了更新我们的统计数据，实际上最后做了一个操作如下（栈）： ``` #0 TABLE_SHARE::clear_version (this=0x7ffeec00ee38) at /opt/mysql/mysql-8.0.21/sql/table.cc:518 #1 0x0000000003680a4d in <lambda(std::unordered_map<std::__cxx11::basic_string<char>, std::unique_ptr<TABLE_SHARE, Table_share_deleter>, std::hash<std::__cxx11::basic_string<char> >, std::equal_to<std::__cxx11::basic_string<char> >, Malloc_allocator<std::pair<const std::__cxx11::basic_string<char>, std::unique_ptr<TABLE_SHARE, Table_share_deleter> > > >::iterator)>::operator()(std::unordered_map<std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >, std::unique_ptr<TABLE_SHARE, Table_share_deleter>, std::hash<std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> > >, std::equal_to<std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> > >, Malloc_allocator<std::pair<std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> > const, std::unique_ptr<TABLE_SHARE, Table_share_deleter> > > >::iterator) const (__closure=0x7fff600ce8a0, my_it=...) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:9831 #2 0x0000000003680d0c in tdc_remove_table (thd=0x7ffed8094550, remove_type=TDC_RT_REMOVE_UNUSED, db=0x7ffed80c4a08 "test", table_name=0x7ffed80c4a20 "e01", has_lock=false) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:9844 #3 0x0000000003d890a9 in mysql_admin_table (thd=0x7ffed8094550, tables=0x7ffed80c4cb8, check_opt=0x7ffed80ba370, operator_name=0x61c06e7 "analyze", lock_type=TL_READ_NO_INSERT, open_for_modify=true, repair_table_use_frm=false, extra_open_options=0, prepare_func=0x0, operator_func= (int (handler::*)(handler * const, THD *, HA_CHECK_OPT *)) 0x3accc64 <handler::ha_analyze(THD*, HA_CHECK_OPT*)>, check_view=0, alter_info=0x7ffed80c4b28, need_to_acquire_shared_backup_lock=true) at /opt/mysql/mysql-8.0.21/sql/sql_admin.cc:1296 #4 0x0000000003d89e77 in Sql_cmd_analyze_table::execute (this=0x7ffed80c5270, thd=0x7ffed8094550) at /opt/mysql/mysql-8.0.21/sql/sql_admin.cc:1549 #5 0x00000000037501d9 in mysql_execute_command (thd=0x7ffed8094550, first_level=true) at /opt/mysql/mysql-8.0.21/sql/sql_parse.cc:4573 ``` 大概看一下做了什么，如下： ``` if (share->ref_count() > 0) { /* Set share's version to zero in order to ensure that it gets automatically deleted once it is no longer referenced. Note that code in TABLE_SHARE::wait_for_old_version() assumes that marking share as old and removal of its unused tables and of the share itself from TDC happens atomically under protection of LOCK_open, or, putting it another way, that TDC does not contain old shares which don't have any tables used. */ if (remove_type != TDC_RT_REMOVE_NOT_OWN_KEEP_SHARE) share->clear_version(); table_cache_manager.free_table(thd, remove_type, share); } ``` 这里判断了是否当前table share正在使用，如果正在使用（很显然我们这个table share是不能直接释放的，因为有select一直持有它）那么将share版本的设置为0（share->clear_version()，实际上这个版本由全局变量refresh_version初始化），目的在于下次如果有使用表定义的时候需要重新打开table share。然后释放了当前没有使用的table cache（类型TDC_RT_REMOVE_UNUSED），如下： ``` TDC_RT_REMOVE_UNUSED - remove all unused TABLE instances (if there are no used instances will also remove TABLE_SHARE). ``` ###三、再次访问表堵塞 当再次访问表的时候（open_table），会去判断如下是否有老的table share存在，如果存在则需要等待释放： ``` share_found: if (!(flags & MYSQL_OPEN_IGNORE_FLUSH)) { if (share->has_old_version()) { /* We already have an MDL lock. But we have encountered an old version of table in the table definition cache which is possible when someone changes the table version directly in the cache without acquiring a metadata lock (e.g. this can happen during "rolling" FLUSH TABLE(S)). Release our reference to share, wait until old version of share goes away and then try to get new version of table share. */ release_table_share(share); ... wait_result = tdc_wait_for_old_version(thd, table_list->db, table_list->table_name, ot_ctx->get_timeout(), deadlock_weight); ``` 首先如果存在判断是否存在的老版本，判断是通过table share的版本和当前全局版本refresh_version进行比对，前面我们知道这里table share的版本已经设置为0，因此这里必然进入release_table_share环节，然后等待持有者的释放（案例窗口1的select查询），然后再次获取table share。等待栈如下： ``` (gdb) bt #0 tdc_wait_for_old_version (thd=0x7ffed8094550, db=0x7ffed802e5c0 "test", table_name=0x7ffed802e5d8 "e01", wait_timeout=31536000, deadlock_weight=0) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:2705 #1 0x0000000003671d7e in open_table (thd=0x7ffed8094550, table_list=0x7ffed802e7c8, ot_ctx=0x7fff600cf1a0) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:3280 #2 0x0000000003675c36 in open_and_process_table (thd=0x7ffed8094550, lex=0x7ffed80b9fe0, tables=0x7ffed802e7c8, counter=0x7ffed80ba038, prelocking_strategy=0x7fff600cf2b8, has_prelocking_list=false, ot_ctx=0x7fff600cf1a0) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:5000 #3 0x0000000003677102 in open_tables (thd=0x7ffed8094550, start=0x7fff600cf260, counter=0x7ffed80ba038, flags=0, prelocking_strategy=0x7fff600cf2b8) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:5664 #4 0x0000000003678993 in open_tables_for_query (thd=0x7ffed8094550, tables=0x7ffed802e7c8, flags=0) at /opt/mysql/mysql-8.0.21/sql/sql_base.cc:6515 ``` 进入waiting for table flush状态 ``` wait_status = mdl_context->m_wait.timed_wait(thd, abstime, true, &stage_waiting_for_table_flush); ``` ###四、Percona修改一处 Percona在上文中已经提到问题如下：  一个关键的修改点如下 官方版本：  Percona版本：  如此修改后analyze不会进入tdc_remove_table函数，那么table share的版本不会设置为0。因此如果使用官方版本小心本问题。
