Oracle 扩充磁盘空间

Oracle 扩充磁盘空间 环境： OS:Oracle Linux Server release 6.3 DB:Oracle 11.2.0.4.0 问题： 根目录磁盘空间不足，还剩6.5G 解决办法： 扩容磁盘空间； 由于安装操作系统时没有使用LVM，不能直接扩容根目录，并且磁盘上的数据库相关文件不能删除； 可以添加新盘，并将数据库文件迁移到新盘上； 1 查看数据库相关文件均在/u01目录下 [root@cjc ~]# cat /home/oracle/.bash_profile  ...... export ORACLE_BASE=/u01/app/oracle export ORACLE_HOME=/u01/app/oracle/product/11.2.0/db_1 ...... SQL> select file_name from dba_data_files; FILE_NAME -------------------------------------------------------------------------------- /u01/app/oracle/oradata/dapuchai/users01.dbf /u01/app/oracle/oradata/dapuchai/undotbs01.dbf /u01/app/oracle/oradata/dapuchai/sysaux01.dbf /u01/app/oracle/oradata/dapuchai/system01.dbf /u01/app/oracle/oradata/dapuchai/cjc_tbs01a.dbf /u01/app/oracle/oradata/dapuchai/ogg_tbs01.dbf 6 rows selected. 2 Linux 添加新分区 ---关机添加100G磁盘，/dev/sdb  [root@dapuchai ~]# df -h Filesystem            Size  Used Avail Use% Mounted on /dev/sda3              28G   20G  6.5G  76% / tmpfs                1004M  239M  765M  24% /dev/shm /dev/sda1             194M   51M  134M  28% /boot [root@cjc ~]# fdisk -l Disk /dev/sda: 32.2 GB, 32212254720 bytes 255 heads, 63 sectors/track, 3916 cylinders Units = cylinders of 16065 * 512 = 8225280 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0x000ccbd2    Device Boot      Start         End      Blocks   Id  System /dev/sda1   *           1          26      204800   83  Linux Partition 1 does not end on cylinder boundary. /dev/sda2              26         287     2097152   82  Linux swap / Solaris Partition 2 does not end on cylinder boundary. /dev/sda3             287        3917    29154304   83  Linux Disk /dev/sdb: 107.4 GB, 107374182400 bytes 255 heads, 63 sectors/track, 13054 cylinders Units = cylinders of 16065 * 512 = 8225280 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0x00000000 3 分区/dev/sdb1  [root@cjc ~]# fdisk /dev/sdb Device contains neither a valid DOS partition table, nor Sun, SGI or OSF disklabel Building a new DOS disklabel with disk identifier 0xf58baf0e. Changes will remain in memory only, until you decide to write them. After that, of course, the previous content won't be recoverable. Warning: invalid flag 0x0000 of partition table 4 will be corrected by w(rite) WARNING: DOS-compatible mode is deprecated. It's strongly recommended to          switch off the mode (command 'c') and change display units to          sectors (command 'u'). Command (m for help): p ---查看  Disk /dev/sdb: 107.4 GB, 107374182400 bytes 255 heads, 63 sectors/track, 13054 cylinders Units = cylinders of 16065 * 512 = 8225280 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0xf58baf0e    Device Boot      Start         End      Blocks   Id  System Command (m for help): n ---新增 Command action    e   extended    p   primary partition (1-4) p Partition number (1-4):  Value out of range. Partition number (1-4): 1 First cylinder (1-13054, default 1):  Using default value 1 Last cylinder, +cylinders or +size{K,M,G} (1-13054, default 13054):  Using default value 13054 Command (m for help): p Disk /dev/sdb: 107.4 GB, 107374182400 bytes 255 heads, 63 sectors/track, 13054 cylinders Units = cylinders of 16065 * 512 = 8225280 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0xf58baf0e    Device Boot      Start         End      Blocks   Id  System /dev/sdb1               1       13054   104856223+  83  Linux Command (m for help): w ---写入 保存 The partition table has been altered! Calling ioctl() to re-read partition table. Syncing disks. [root@cjc ~]# fdisk -l Disk /dev/sda: 32.2 GB, 32212254720 bytes 255 heads, 63 sectors/track, 3916 cylinders Units = cylinders of 16065 * 512 = 8225280 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0x000ccbd2    Device Boot      Start         End      Blocks   Id  System /dev/sda1   *           1          26      204800   83  Linux Partition 1 does not end on cylinder boundary. /dev/sda2              26         287     2097152   82  Linux swap / Solaris Partition 2 does not end on cylinder boundary. /dev/sda3             287        3917    29154304   83  Linux Disk /dev/sdb: 107.4 GB, 107374182400 bytes 255 heads, 63 sectors/track, 13054 cylinders Units = cylinders of 16065 * 512 = 8225280 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0xf58baf0e    Device Boot      Start         End      Blocks   Id  System /dev/sdb1               1       13054   104856223+  83  Linux 4 格式化 [root@cjc ~]# mkfs -t ext4 /dev/sdb1 mke2fs 1.41.12 (17-May-2010) Filesystem label= OS type: Linux Block size=4096 (log=2) Fragment size=4096 (log=2) Stride=0 blocks, Stripe width=0 blocks 6553600 inodes, 26214055 blocks 1310702 blocks (5.00%) reserved for the super user First data block=0 Maximum filesystem blocks=4294967296 800 block groups 32768 blocks per group, 32768 fragments per group 8192 inodes per group Superblock backups stored on blocks:  32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,  4096000, 7962624, 11239424, 20480000, 23887872 Writing inode tables: done                             Creating journal (32768 blocks): done Writing superblocks and filesystem accounting information: done This filesystem will be automatically checked every 21 mounts or 180 days, whichever comes first.  Use tune2fs -c or -i to override. 5 挂载 [root@cjc ~]# mkdir /u02 [root@cjc ~]# mount /dev/sdb1 /u02 [root@cjc ~]# df -h Filesystem            Size  Used Avail Use% Mounted on /dev/sda3              28G   20G  6.5G  76% / tmpfs                1004M   88K 1004M   1% /dev/shm /dev/sda1             194M   51M  134M  28% /boot /dev/sdb1              99G  188M   94G   1% /u02 6 迁移/u01到新加的盘 [root@cjc ~]# mv /u01 /u03 [root@cjc ~]# mv /u02 /u01 mv: cannot move `/u02' to `/u01': Device or resource busy [root@cjc ~]# umount /u02 [root@cjc ~]# mv /u02 /u01 [root@cjc ~]# mount /dev/sdb1 /u01 [root@cjc ~]# mv /u03/* /u01 [root@cjc ~]# df -h Filesystem            Size  Used Avail Use% Mounted on /dev/sda3              28G   14G   13G  54% / tmpfs                1004M   88K 1004M   1% /dev/shm /dev/sda1             194M   51M  134M  28% /boot /dev/sdb1              99G  6.0G   88G   7% /u01 [root@cjc /]# lsblk NAME   MAJ:MIN RM   SIZE RO TYPE MOUNTPOINT sr0     11:0    1  1024M  0 rom   sr1     11:1    1  1024M  0 rom   sda      8:0    0    30G  0 disk  ├─sda1   8:1    0   200M  0 part /boot ├─sda2   8:2    0     2G  0 part [SWAP] └─sda3   8:3    0  27.8G  0 part / sdb      8:16   0   100G  0 disk  └─sdb1   8:17   0   100G  0 part /u01 7 添加自动挂载 [root@cjc ~]# vi /etc/fstab  ...... /dev/sdb1               /u01                    ext4    defaults        0 0 8 启动数据库 [root@cjc ~]# su - oracle [oracle@cjc ~]$ lsnrctl start [oracle@cjc ~]$ sqlplus / as sysdba SQL*Plus: Release 11.2.0.4.0 Production on Sat Jan 11 15:00:47 2020 Copyright (c) 1982, 2013, Oracle.  All rights reserved. Connected to an idle instance. SQL> startup ORACLE instance started. Total System Global Area  839282688 bytes Fixed Size     2257880 bytes Variable Size   541068328 bytes Database Buffers   289406976 bytes Redo Buffers     6549504 bytes Database mounted. Database opened. SQL> conn cjc  Enter password:  Connected. SQL> select count(*) from t1;   COUNT(*) ---------- 1 欢迎关注我的微信公众号"IT小Chen"，共同学习，共同成长！！！
