今天负责报表的同事反馈在DG库查询时出现如下报错
ORA-01578:ORACLE数据块损坏(文件号6,块号 2494856)ORA-01110:数据文件6: '/oradata/PMSDG/o1 mf users_molczgmn_.dbfORA-26040:数据块是使用 NOLOGGING 选项加载的
可以看到报错是数据文件损坏,提示了file id和block id

在 Oracle Data Guard 环境中,如果  备库数据文件 出现坏块,而主库正常,如何来修复呢?这里假设备库是  Physical Standby 模式。

如果是逻辑备库则如下的方法1/2不适用。


一. 确认问题

  确认坏块信息

在备库执行以下命令查看坏块信息:

SELECT * FROM V$DATABASE_BLOCK_CORRUPTION;

  检查具体受影响的数据文件

查看坏块对应的数据文件编号和名称:(主备均查询一下,确认主库是否也有损坏)

SELECT FILE_ID, FILE_NAME
FROM DBA_DATA_FILES
WHERE FILE_ID IN (SELECT FILE# FROM V$DATABASE_BLOCK_CORRUPTION);

二. 修复方法

方法 1:通过主库恢复坏块

在 Data Guard 环境中, 如果确认主库没有损坏 只有备库出现文件损坏,可以直接通过rman来修复

1.1 停止备库的日志应用

在备库停止日志应用:

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL;

1.2 恢复坏块

通过 RMAN 恢复受影响的数据文件:

登录到备库的 RMAN:

rman target /RMAN> RECOVER DATAFILE 6 BLOCK 2494856;Starting recover at 02-JAN-25
using target database control file instead of recovery catalog
allocated channel: ORA_DISK_1
channel ORA_DISK_1: SID=200 device type=DISK
starting media recovery
media recovery complete, elapsed time: 00:00:00
Finished recover at 02-JAN-25
RMAN>

RMAN 会自动从主库提取所需的日志恢复受影响的块。

1.3 启动日志应用

修复完成后,重新启动日志应用:

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT FROM SESSION;

方法 2:从主库复制数据文件

如果坏块数量较多或  RECOVER 无法成功,可以直接从主库复制整个数据文件。

2.1 确认数据文件路径

在主库和备库执行以下查询,确认数据文件路径一致:

SELECT FILE_ID, FILE_NAME FROM DBA_DATA_FILES;

2.2 在主库创建数据文件备份

登录到主库的 RMAN,备份受影响的数据文件:

[oracle@PMS~]$ rman target /
Recovery Manager: Release 11.2.0.4.0 - Production on Thu Jan 2 22:46:31 2025
Copyright (c) 1982, 2011, Oracle and/or its affiliates.  All rights reserved.
connected to target database: PMS (DBID=4262015389)
RMAN> BACKUP AS COPY DATAFILE 6 FORMAT '/home/oracle/o1 mf users_molczgmn_.dbf';
Starting backup at 02-JAN-25
using target database control file instead of recovery catalog
allocated channel: ORA_DISK_1
channel ORA_DISK_1: SID=764 instance=pms2 device type=DISK
channel ORA_DISK_1: starting datafile copy
input datafile file number=00006 name=+DATA/pms/datafile/o1 mf users_molczgmn_.dbf
output file name=/home/oracle/o1 mf users_molczgmn_.dbf tag=TAG20250102T224636 RECID=4 STAMP=1189378160
channel ORA_DISK_1: datafile copy complete, elapsed time: 00:02:45
Finished backup at 02-JAN-25
Starting Control File and SPFILE Autobackup at 02-JAN-25
piece handle=+ARCH/pms/autobackup/2025_01_02/s_1189378162.29728.1189378163 comment=NONE
Finished Control File and SPFILE Autobackup at 02-JAN-25

2.3 传输备份到备库

将备份文件传输到备库相同路径:

scp -P 11122 o1 mf users_molczgmn_.dbf oracle@10.xx.xx.xx:/home/oracle

2.4 在备库切换数据文件

在备库停止日志应用:

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL;

登录到备库的 RMAN,切换到新数据文件:

启动数据库到mount

注册数据文件副本 CATALOG DATAFILECOPY '/home/oracle/o1 mf users_molczgmn_.dbf'; RESTORE DATAFILE 6 ; RECOVER DATAFILE 6; 开启数据库 alter database open; [oracle@pmsdg ~]$ rman target / Recovery Manager: Release 11.2.0.4.0 - Production on Thu Jan 2 22:14:57 2025 Copyright (c) 1982, 2011, Oracle and/or its affiliates.  All rights reserved. connected to target database: PMS(DBID=4262015389) RMAN> catalog start with '/home/oracle/o1 mf users_molczgmn_.dbf'; searching for all files that match the pattern /home/oracle/o1 mf users_molczgmn_.dbf List of Files Unknown to the Database ===================================== File Name: /home/oracle/o1 mf users_molczgmn_.dbf Do you really want to catalog the above files (enter YES or NO)? yes cataloging files... cataloging done List of Cataloged Files ======================= File Name: /home/oracle/o1 mf users_molczgmn_.dbf --将备库启动到mount阶段. [oracle@pmsdg]$ sqlplus / as sysdba SQL*Plus: Release 11.2.0.4.0 Production on  Thu Jan 2  22:27:50 2025 Copyright (c) 1982, 2013, Oracle.  All rights reserved. Connected to: Oracle Database 11g Enterprise Edition Release 11.2.0.4.0 - 64bit Production With the Partitioning, OLAP, Data Mining and Real Application Testing options SQL> shutdown immediate; Database closed. Database dismounted. ORACLE instance shut down. SYS@orcl150> startup mount; ORACLE instance started. Total System Global Area 1586708480 bytes Fixed Size                  2253624 bytes Variable Size             989859016 bytes Database Buffers          587202560 bytes Redo Buffers                7393280 bytes Database mounted. [oracle@pmsdg]$ rman target / Recovery Manager: Release 11.2.0.4.0 - Production on Thu Jan 2 22:28:24 2025 Copyright (c) 1982, 2011, Oracle and/or its affiliates.  All rights reserved. connected to target database: PMSDG (DBID=4262015389, not open) RMAN> restore datafile 6; Starting restore at 02-JAN-25 using target database control file instead of recovery catalog allocated channel: ORA_DISK_1 channel ORA_DISK_1: SID=63 device type=DISK channel ORA_DISK_1: starting datafile backup set restore channel ORA_DISK_1: specifying datafile(s) to restore from backup set channel ORA_DISK_1: restoring datafile 00006 to /oradata/PMSDG/o1 mf users_molczgmn_.dbf channel ORA_DISK_1: reading from backup piece /home/oracle/o1 mf users_molczgmn_.dbf channel ORA_DISK_1: piece handle=/home/oracle/o1 mf users_molczgmn_.dbf tag=TAG20230203T204533 channel ORA_DISK_1: restored backup piece 1 channel ORA_DISK_1: restore complete, elapsed time: 00:06:01 Finished restore at 02-JAN-25 RMAN> recover datafile 6; Starting recover at  02-JAN-25 using target database control file instead of recovery catalog allocated channel: ORA_DISK_1 channel ORA_DISK_1: SID=63 device type=DISK starting media recovery media recovery complete, elapsed time: 00:05:01 Finished recover at 02-JAN-25 RMAN> alter database open; database opened

2.5 启动日志应用

修复完成后,重新启动日志应用:

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT FROM SESSION;

方法 3:重建备库(简单粗暴)

如果坏块影响严重且以上方法无法修复,可以考虑重新同步备库,如果是数据量比较小的推荐这样操作

如果是数据量很大的话 推荐前面的两种方法:

3.1 RMAN duplicate方式重建备库

创建主库的全量备份(包括数据文件、控制文件、归档日志):

rman target sys/xxxx@pms auxiliary sys/xxxx@PMSDGrun
{
allocate channel d1 type disk;
allocate channel d2 type disk;
allocate channel d3 type disk;
allocate channel d4 type disk;
allocate auxiliary channel c1 type disk;
allocate auxiliary channel c2 type disk;
allocate auxiliary channel c3 type disk;
allocate auxiliary channel c4 type disk;
duplicate target database for standby from active database nofilenamecheck;
}

3.2 重新开始归档应用

alter database recover managed standby database cancel;alter database open;alter database recover managed standby database using current logfile disconnect from session;

在备库使用 RMAN 恢复备份并重新配置 Data Guard 环境。


三. 验证修复

  检查坏块是否修复

在备库执行以下命令,确认坏块是否已修复:

SELECT * FROM V$DATABASE_BLOCK_CORRUPTION;

  确认日志应用正常

查看备库是否同步正常:

--日志传输状态
standby>
select 'Last Applied : ' Logs,
       to_char(next_time, 'DD-MON-YY HH24:MI:SS') Time
  from v$archived_log
 where sequence# =
       (select max(sequence#) from v$archived_log where applied = 'YES')
union
select 'Last Received : ' Logs,
       to_char(next_time, 'DD-MON-YY HH24:MI:SS') Time
  from v$archived_log
 where sequence# = (select max(sequence#) from v$archived_log);-- 最后应用的sequence序列
Standby>
select al.thrd "Thread",
       almax   "Last Seq Received",
       lhmax   "Last Seq Applied"
  from (select thread# thrd, max(sequence#) almax
          from v$archived_log
         where resetlogs_change# =
               (select resetlogs_change# from v$database)
         group by thread#) al,
       (select thread# thrd, max(sequence#) lhmax
          from v$log_history
         where first_time = (select max(first_time) from v$log_history)
         group by thread#) lh
 where al.thrd = lh.thrd;

四. 注意事项 优先通过主库恢复

  1. 如果坏块较少,推荐使用方法 1 恢复。
  2. 如果坏块较多,直接使用方法 2 替换数据文件。
  3. 如果数据库比较小 也推荐重建方式  简单直接,如果数据库太大 重建耗时太久 推荐前两种方式
  4. 另外如果是主库有文件损坏,备库正常方法2也适用。
