1. 故障背景
1.1 事件概述
202X年X月X日，某用户的Oracle数据库在上午9点至10点期间发生故障，导致部分业务无法正常运行。经初步分析，发现数据库报出
ORA-00600 内部错误。该错误是Oracle的一个通用错误，通常由数据库内部逻辑异常、数据块损坏或存储问题引起。
1.2 影响范围
2. 故障排查与分析
2.1 错误日志分析
通过
alert.log 日志文件，我们发现了如下错误信息：
ORA-00600: , : [13013], [5001], [126801], [109382409], [101], [109382437], [17], [], [], [], [], [] Incident details in: /opt/app/oracle/diag/rdbms/jcd/jcd/incident/incdir_99948/jcd_ora_23550_i99948.trc Non critical error ORA-48113 caught while writing to trace file "/opt/app/oracle/diag/rdbms/jcd/jcd/incident/incdir_99948/jcd_ora_23550_i99948.trc" ORA-00600: , : [13013], [5001], [126801], [109382408], [102], [109382433], [17], [], [], [], [], [] Incident details in: /opt/app/oracle/diag/rdbms/jcd/jcd/incident/incdir_99980/jcd_ora_445_i99980.trc ORA-00600: , : [13013], [5001], [126801], [109382409], [123], [109382437], [17], [], [], [], [], [] Incident details in: /opt/app/oracle/diag/rdbms/jcd/jcd/incident/incdir_101652/jcd_ora_8586_i101652.trc ORA-00600: , : [13013], [5001], [126801], [109382409], [168], [109382437], [17], [], [], [], [], [] ORA-00600: , : [13013], [5001], [126801], [109382406], [99], [109382433], [17], [], [], [], [], [] ORA-00600: , : [13013], [5001], [126801], [109382405], [152], [109382433], [17], [], [], [], [], []
ORA-00600 是Oracle的内部错误，
2662 可能与数据块的SCN不一致有关。
ORA-600 [13013] Format: ORA-600 [13013] [a] [b] [c] [d] [e] [f] This format relates to Oracle Server 8.0.3 and above Arg [a] Passcount Arg [b] Data Object number Arg [c] Tablespace Decimal Relative DBA (RDBA) of block containing the row to be updated Arg [d] Row Slot number Arg [e] Decimal RDBA of block being updated (Typically same as [c]) Arg [f] Code
ORA-00600: internal error code, arguments: [13013], [5001], [268], [8457615], [5], [8457615], [17], [], [], [], [], []
2.2 确认损坏数据块
使用
dbms_utility.data_block_address_file 及
dbms_utility.data_block_address_block 确定损坏的数据块位置：
SELECT dbms_utility.data_block_address_file(109382409) rfile, dbms_utility.data_block_address_block(109382409) rblocksFROM dual; RFILE RBLOCKS---------- ---------- 26 330505select dbms_utility.data_block_address_file(109382408) rfile, dbms_utility.data_block_address_block(109382408) blocs from dual; RFILE RBLOCKS---------- ---------- 26 330504select dbms_utility.data_block_address_file(109382406) rfile, dbms_utility.data_block_address_block(109382406) rblocks from dual; RFILE RBLOCKS---------- ---------- 26 330502select dbms_utility.data_block_address_file(109382405) rfile, dbms_utility.data_block_address_block(109382405) rblocks from dual; RFILE RBLOCKS---------- ---------- 26 330501
查询结果显示损坏的文件编号和块号。
确认对象:
SQL> set linesize 999 pagesize 9999SQL> select owner,segment_name,segment_type,tablespace_name from dba_extents where file_id =26 and 330505 between block_id and block_id + blocks -1; OWNER SEGMENT_NAME SEGMENT_TYPE TABLESPACE_NAME ---------- ---------- ---------- -------------------- XHSD_JCD JCD_PUB_YHBMB TABLE TS_PUB_DATA
同时dbv校验26号文件: 无物理坏块!
尝试执行分析: analyze table XHSD_JCD.JCD_PUB_YHBMB validate structure cascade online; ERROR at line 1: ORA-08104: this index object 130036 is being online built or rebuilt
2.3 关联对象检查
通过
DBA_EXTENTS 确定该损坏数据块对应的表或索引：
确认130036索引:select object_name,object_type from dba_object where object_id='130036'; OBJECT_NAME OBJECT_TYPE---------------------------------------------------------PK_JCD_PUB_YHBMB INDEX
结果显示该数据块属于
IDX_ORDERS 索引。
//与客户沟通,此时正在重建索引.无法进行分析.
2.4 索引问题分析
由于查询过程中报出
ORA-08104: this index object is being online built or rebuilt，客户重建索引后仍无法继续分析:
ANALYZE INDEX IDX_ORDERS VALIDATE STRUCTURE;
发现索引结构损坏，导致查询时无法正常访问。
3. 故障处理方案
3.1 索引修复
由于
IDX_ORDERS 索引损坏，我们先尝试使用
DBMS_REPAIR.ONLINE_INDEX_CLEAN 进行清理：
analyze table XHSD_JCD.JCD_PUB_YHBMB validate structure cascade online; ERROR at line 1: ORA-08104: this index object 130036 is being online built or rebuilt
执行清理索引创建操作:
SQL> DECLARE isClean BOOLEAN; BEGIN isClean := DBMS_REPAIR.ONLINE_INDEX_CLEAN(130036); END; /
再次手动进行rebulid:
alter index XHSD_JCD.PK_JCD_PUB_YHBMB rebuild
再次进行分析资源被占用,别hang住sql占用:
analyze table XHSD_JCD.JCD_PUB_YHBMB validate structure cascade online; analyze table XHSD_JCD.JCD_PUB_YHBMB validate structure ANALYZE INDEX XHSD_JCD.PK_JCD_PUB_YHBMB VALIDATE STRUCTURE;
3.2 检查锁定对象
查询锁定的会话，确认是否有进程阻塞索引重建：
select l.session_id,o.owner,o.object_name from v$locked_object l,dba_objects o where l.object_id=o.object_id; SESSION_ID OWNER OBJECT_NAME---------- ---------- -------------------- 780 XHSD_JCD JCD_PUB_YHBMB 627 XHSD_JCD JCD_PUB_YHBMB 1152 XHSD_JCD JCDMS_DZTSYCCL
操作系统层面杀锁:
select a.spid,b.sid,b.serial#,b.username from v$process a,v$session b where a.addr=b.paddr and b.sid=780;select a.spid,b.sid,b.serial#,b.username from v$process a,v$session b where a.addr=b.paddr and b.sid=627;select a.spid,b.sid,b.serial#,b.username from v$process a,v$session b where a.addr=b.paddr and b.sid=1152;
kill -9进行操作系统层面杀锁
再次执行分析成功:
analyze table XHSD_JCD.JCD_PUB_YHBMB validate structure cascade online; analyze table XHSD_JCD.JCD_PUB_YHBMB validate structure ANALYZE INDEX XHSD_JCD.PK_JCD_PUB_YHBMB VALIDATE STRUCTURE;
此时客户给出问题SQL:
执行SQL 会话hang住
UPDATE XHSD_JCD.PUB_YHBMB SET DLBZ = '1' WHERE DLH='00560';
后台出现: ORA-07445: exception encountered: core dump [kduudm()+1798] [SIGSEGV] [ADDR:0x1E1000000] [PC:0x4BCB2A2] [Address not mapped to object] []
//对于该错误代码,Mos并无相关记录.
Wed Mar 03 11:49:46 2021 Exception [type: SIGSEGV, Address not mapped to object] [ADDR:0x1E1000000] [PC:0x4BCB2A2, kduudm()+1798] [flags: 0x0, count: 1] Errors in file /opt/app/oracle/diag/rdbms/jcd/jcd/trace/jcd_ora_9960.trc (incident=100772): ORA-07445: exception encountered: core dump [kduudm()+1798] [SIGSEGV] [ADDR:0x1E1000000] [PC:0x4BCB2A2] [Address not mapped to object] [] Incident details in: /opt/app/oracle/diag/rdbms/jcd/jcd/incident/incdir_100772/jcd_ora_9960_i100772.trc Use ADRCI or Support Workbench to package the incident. See Note 411.1 at My Oracle Support for error and packaging details. Wed Mar 03 11:49:48 2021 Dumping diagnostic data in directory=[cdmp_20210303114948], requested by (instance=1, osid=9960), summary=[incident=100772]. Wed Mar 03 11:49:49 2021 Sweep [inc][100772]: completed Sweep [inc2][100772]: completed
询问客户视图创建SQL:
create or replace view pub_yhbmb asselect DLH,BM,YHM,KL,SYBZ,QYRQ,ZZRQ,DLBZ,SMfrom jcd_PUB_YHBMB;
对原表执行delete也hang住:
delete from jcd_pub_yhbmb WHERE DLH='00560';
select语句数据获取正常:
select * from XHSD_JCD.jcd_pub_yhbmb
尝试跟踪delete以及update语句,但sql_trace以及10046无输出.
最终尝试手动通过CTS创建一张测试表进行DML测试可以执行:
create table XHSD_JCD.test as select * from XHSD_JCD.jcd_PUB_YHBMB;delete from XHSD_JCD.test WHERE DLH='00560';
最终建议客户使用CTS重建业务表业务正常.
相关Mos: How to Use DBMS_REPAIR.ONLINE_INDEX_CLEAN For The Cleanup Of Online Index Failing With ORA-08104? (文档 ID 1378173.1) How to Cleanup and Rebuild an Interrupted Online Index Rebuild - ORA-8104 , ORA-8106 (文档 ID 272735.1) Session Was Killed During The Rebuild Of Index ORA-08104 (文档 ID 375856.1)
4.需要总结的知识点:
- 10046各个级别的区别
- debug与10046事件关系与使用方法区别
- 处理表被占用锁定v$locked_object
- Dblink on Physical standby - ORA-16000 (Doc ID 1296288.1)文档
- Query with multiple dblinks in ADG / read-only database fails with ORA-16000 (Doc ID 2462936.1)
- 301137.1 OS Watcher User Guide
- 580513.1 How To Start OSWatcher Black Box Every System Boot (Linux specific)
操作系统层面与数据库层面杀锁.
