本节简单介绍了PostgreSQL中的HTAB如何动态扩展,这是第2部分,结合代码进行解析. ### 一、数据结构 ``` /* * Top control structure for a hashtable --- in a shared table, each backend * has its own copy (OK since no fields change at runtime) * 哈希表的顶层控制结构. * 在这个共享哈希表中,每一个后台进程都有自己的拷贝 * (之所以没有问题是因为fork出来后,在运行期没有字段会变化) */ struct HTAB { //指向共享的控制信息 HASHHDR *hctl; /* => shared control information */ //段目录 HASHSEGMENT *dir; /* directory of segment starts */ //哈希函数 HashValueFunc hash; /* hash function */ //哈希键比较函数 HashCompareFunc match; /* key comparison function */ //哈希键拷贝函数 HashCopyFunc keycopy; /* key copying function */ //内存分配器 HashAllocFunc alloc; /* memory allocator */ //内存上下文 MemoryContext hcxt; /* memory context if default allocator used */ //表名(用于错误信息) char *tabname; /* table name (for error messages) */ //如在共享内存中,则为T bool isshared; /* true if table is in shared memory */ //如为T,则固定大小不能扩展 bool isfixed; /* if true, don't enlarge */ /* freezing a shared table isn't allowed, so we can keep state here */ //不允许冻结共享表,因此这里会保存相关状态 bool frozen; /* true = no more inserts allowed */ /* We keep local copies of these fixed values to reduce contention */ //保存这些固定值的本地拷贝,以减少冲突 //哈希键长度(以字节为单位) Size keysize; /* hash key length in bytes */ //段大小,必须为2的幂 long ssize; /* segment size --- must be power of 2 */ //段偏移,ssize的对数 int sshift; /* segment shift = log2(ssize) */ }; /* * Header structure for a hash table --- contains all changeable info * 哈希表的头部结构 -- 存储所有可变信息 * * In a shared-memory hash table, the HASHHDR is in shared memory, while * each backend has a local HTAB struct. For a non-shared table, there isn't * any functional difference between HASHHDR and HTAB, but we separate them * anyway to share code between shared and non-shared tables. * 在共享内存哈希表中,HASHHDR位于共享内存中,每一个后台进程都有一个本地HTAB结构. * 对于非共享哈希表,HASHHDR和HTAB没有任何功能性的不同, * 但无论如何,我们还是把它们区分为共享和非共享表. */ struct HASHHDR { /* * The freelist can become a point of contention in high-concurrency hash * tables, so we use an array of freelists, each with its own mutex and * nentries count, instead of just a single one. Although the freelists * normally operate independently, we will scavenge entries from freelists * other than a hashcode's default freelist when necessary. * 在高并发的哈希表中,空闲链表会成为竞争热点,因此我们使用空闲链表数组, * 数组中的每一个元素都有自己的mutex和条目统计,而不是使用一个. * * If the hash table is not partitioned, only freeList[0] is used and its * spinlock is not used at all; callers' locking is assumed sufficient. * 如果哈希表没有分区,那么只有freelist[0]元素是有用的,自旋锁没有任何用处; * 调用者锁定被认为已足够OK. */ /* Number of freelists to be used for a partitioned hash table. */ //#define NUM_FREELISTS 32 FreeListData freeList[NUM_FREELISTS]; /* These fields can change, but not in a partitioned table */ //这些域字段可以改变,但不适用于分区表 /* Also, dsize can't change in a shared table, even if unpartitioned */ //同时,就算是非分区表,共享表的dsize也不能改变 //目录大小 long dsize; /* directory size */ //已分配的段大小(<= dsize) long nsegs; /* number of allocated segments (<= dsize) */ //正在使用的最大桶ID uint32 max_bucket; /* ID of maximum bucket in use */ //进入整个哈希表的模掩码 uint32 high_mask; /* mask to modulo into entire table */ //进入低位哈希表的模掩码 uint32 low_mask; /* mask to modulo into lower half of table */ /* These fields are fixed at hashtable creation */ //下面这些字段在哈希表创建时已固定 //哈希键大小(以字节为单位) Size keysize; /* hash key length in bytes */ //所有用户元素大小(以字节为单位) Size entrysize; /* total user element size in bytes */ //分区个数(2的幂),或者为0 long num_partitions; /* # partitions (must be power of 2), or 0 */ //目标的填充因子 long ffactor; /* target fill factor */ //如目录是固定大小,则该值为dsize的上限值 long max_dsize; /* 'dsize' limit if directory is fixed size */ //段大小,必须是2的幂 long ssize; /* segment size --- must be power of 2 */ //段偏移,ssize的对数 int sshift; /* segment shift = log2(ssize) */ //一次性分配的条目个数 int nelem_alloc; /* number of entries to allocate at once */ #ifdef HASH_STATISTICS /* * Count statistics here. NB: stats code doesn't bother with mutex, so * counts could be corrupted a bit in a partitioned table. * 统计信息. * 注意:统计相关的代码不会影响mutex,因此对于分区表,统计可能有一点点问题 */ long accesses; long collisions; #endif }; /* * Per-freelist data. * 空闲链表数据. * * In a partitioned hash table, each freelist is associated with a specific * set of hashcodes, as determined by the FREELIST_IDX() macro below. * nentries tracks the number of live hashtable entries having those hashcodes * (NOT the number of entries in the freelist, as you might expect). * 在一个分区哈希表中,每一个空闲链表与特定的hashcodes集合相关,通过下面的FREELIST_IDX()宏进行定义. * nentries跟踪有这些hashcodes的仍存活的hashtable条目个数. * (注意不要搞错,不是空闲的条目个数) * * The coverage of a freelist might be more or less than one partition, so it * needs its own lock rather than relying on caller locking. Relying on that * wouldn't work even if the coverage was the same, because of the occasional * need to "borrow" entries from another freelist; see get_hash_entry(). * 空闲链表的覆盖范围可能比一个分区多或少,因此需要自己的锁而不能仅仅依赖调用者的锁. * 依赖调用者锁在覆盖面一样的情况下也不会起效,因为偶尔需要从另一个自由列表“借用”条目,详细参见get_hash_entry() * * Using an array of FreeListData instead of separate arrays of mutexes, * nentries and freeLists helps to reduce sharing of cache lines between * different mutexes. * 使用FreeListData数组而不是一个独立的mutexes,nentries和freelists数组有助于减少不同mutexes之间的缓存线共享. */ typedef struct { //该空闲链表的自旋锁 slock_t mutex; /* spinlock for this freelist */ //相关桶中的条目个数 long nentries; /* number of entries in associated buckets */ //空闲元素链 HASHELEMENT *freeList; /* chain of free elements */ } FreeListData; /* * HASHELEMENT is the private part of a hashtable entry. The caller's data * follows the HASHELEMENT structure (on a MAXALIGN'd boundary). The hash key * is expected to be at the start of the caller's hash entry data structure. * HASHELEMENT是哈希表条目的私有部分. * 调用者的数据按照HASHELEMENT结构组织(位于MAXALIGN的边界). * 哈希键应位于调用者hash条目数据结构的开始位置. */ typedef struct HASHELEMENT { //链接到相同桶中的下一个条目 struct HASHELEMENT *link; /* link to next entry in same bucket */ //该条目的哈希函数结果 uint32 hashvalue; /* hash function result for this entry */ } HASHELEMENT; /* Hash table header struct is an opaque type known only within dynahash.c */ //哈希表头部结构,非透明类型,用于dynahash.c typedef struct HASHHDR HASHHDR; /* Hash table control struct is an opaque type known only within dynahash.c */ //哈希表控制结构,非透明类型,用于dynahash.c typedef struct HTAB HTAB; /* Parameter data structure for hash_create */ //hash_create使用的参数数据结构 /* Only those fields indicated by hash_flags need be set */ //根据hash_flags标记设置相应的字段 typedef struct HASHCTL { //分区个数(必须是2的幂) long num_partitions; /* # partitions (must be power of 2) */ //段大小 long ssize; /* segment size */ //初始化目录大小 long dsize; /* (initial) directory size */ //dsize上限 long max_dsize; /* limit to dsize if dir size is limited */ //填充因子 long ffactor; /* fill factor */ //哈希键大小(字节为单位) Size keysize; /* hash key length in bytes */ //参见上述数据结构注释 Size entrysize; /* total user element size in bytes */ // HashValueFunc hash; /* hash function */ HashCompareFunc match; /* key comparison function */ HashCopyFunc keycopy; /* key copying function */ HashAllocFunc alloc; /* memory allocator */ MemoryContext hcxt; /* memory context to use for allocations */ //共享内存中的哈希头部结构地址 HASHHDR *hctl; /* location of header in shared mem */ } HASHCTL; /* A hash bucket is a linked list of HASHELEMENTs */ //哈希桶是HASHELEMENTs链表 typedef HASHELEMENT *HASHBUCKET; /* A hash segment is an array of bucket headers */ //hash segment是桶数组 typedef HASHBUCKET *HASHSEGMENT; /* * Hash functions must have this signature. * Hash函数必须有它自己的标识 */ typedef uint32 (*HashValueFunc) (const void *key, Size keysize); /* * Key comparison functions must have this signature. Comparison functions * return zero for match, nonzero for no match. (The comparison function * definition is designed to allow memcmp() and strncmp() to be used directly * as key comparison functions.) * 哈希键对比函数必须有自己的标识. * 如匹配则对比函数返回0,不匹配返回非0. * (对比函数定义被设计为允许在对比键值时可直接使用memcmp()和strncmp()) */ typedef int (*HashCompareFunc) (const void *key1, const void *key2, Size keysize); /* * Key copying functions must have this signature. The return value is not * used. (The definition is set up to allow memcpy() and strlcpy() to be * used directly.) * 键拷贝函数必须有自己的标识. * 返回值无用. */ typedef void *(*HashCopyFunc) (void *dest, const void *src, Size keysize); /* * Space allocation function for a hashtable --- designed to match malloc(). * Note: there is no free function API; can't destroy a hashtable unless you * use the default allocator. * 哈希表的恐惧分配函数 -- 被设计为与malloc()函数匹配. * 注意:这里没有释放函数API;不能销毁哈希表,除非使用默认的分配器. */ typedef void *(*HashAllocFunc) (Size request); ``` 其结构如下图所示：  扩展后的结构如下图所示:  ### 二、源码解读 主要的函数是expand_table 1.分配新桶,HTAB的最大桶数max_bucket+1 2.根据新桶号计算段号和段内编号 3.如需扩展段,则扩展(\*2) 4.获取新桶号对应的原桶号,目的是为了把原桶号中的数据迁移到新桶中.新桶号和原桶号相差low_mask 5.扫描旧桶,重建旧桶元素链表,构造新桶元素链表 ``` /* * Expand the table by adding one more hash bucket. * 通过增加一个或者多个hash bucket扩展hash表 */ static bool expand_table(HTAB *hashp) { HASHHDR *hctl = hashp->hctl;//hash控制结构 HASHSEGMENT old_seg,//原seg new_seg;//新seg long old_bucket,//原bucket new_bucket;//新bucket long new_segnum,//新seg号 new_segndx;//新seg索引(segment中的编号) long old_segnum,//新seg号 old_segndx;//原seg索引 HASHBUCKET *oldlink,//原桶 *newlink;//新桶 HASHBUCKET currElement,//当前元素 nextElement;//下一元素 //#define IS_PARTITIONED(hctl) ((hctl)->num_partitions != 0) Assert(!IS_PARTITIONED(hctl)); #ifdef HASH_STATISTICS hash_expansions++; #endif new_bucket = hctl->max_bucket + 1;//新增加一个bucket new_segnum = new_bucket >> hashp->sshift;//取商数 new_segndx = MOD(new_bucket, hashp->ssize);//取余数 if (new_segnum >= hctl->nsegs) { //扩展segment,每次扩展一倍 /* Allocate new segment if necessary -- could fail if dir full */ if (new_segnum >= hctl->dsize) if (!dir_realloc(hashp)) return false; if (!(hashp->dir[new_segnum] = seg_alloc(hashp)))//为新的seg对应的bucket分配空间 return false; hctl->nsegs++; } /* OK, we created a new bucket */ //已完成创建 hctl->max_bucket++; /* * *Before* changing masks, find old bucket corresponding to same hash * values; values in that bucket may need to be relocated to new bucket. * Note that new_bucket is certainly larger than low_mask at this point, * so we can skip the first step of the regular hash mask calc. * 在修改掩码前,为新的bucket找到对应的原bucket,原bucket中的元素keneng需要迁移到新的bucket上. * 注意new_bucket肯定会比low_mask要大,可以跳过常规的hash掩码计算的第一个步骤. */ old_bucket = (new_bucket & hctl->low_mask); /* * If we crossed a power of 2, readjust masks. * 如果new_bucket是2的n次方,调整掩码 */ if ((uint32) new_bucket > hctl->high_mask) { hctl->low_mask = hctl->high_mask;//如15->31 hctl->high_mask = (uint32) new_bucket | hctl->low_mask;//如31->63 } /* * Relocate records to the new bucket. NOTE: because of the way the hash * masking is done in calc_bucket, only one old bucket can need to be * split at this point. With a different way of reducing the hash value, * that might not be true! * 重定位记录到新的bucket上. * 注意:由于通过方法calc_bucket计算hash掩码,这时只需要拆分一个bucket. * */ old_segnum = old_bucket >> hashp->sshift;//计算原seg号 old_segndx = MOD(old_bucket, hashp->ssize);//计算原seg中的索引号 old_seg = hashp->dir[old_segnum];//旧seg new_seg = hashp->dir[new_segnum];//新seg oldlink = &old_seg[old_segndx];//原bucket指针 newlink = &new_seg[new_segndx];//新bucket指针 for (currElement = *oldlink; currElement != NULL; currElement = nextElement)//循环遍历 { nextElement = currElement->link; if ((long) calc_bucket(hctl, currElement->hashvalue) == old_bucket) { *oldlink = currElement; oldlink = &currElement->link;//重新构造原bucket } else { *newlink = currElement;//构造新bucket newlink = &currElement->link; } } /* don't forget to terminate the rebuilt hash chains... */ //不要忘了终止重建后的hash链 *oldlink = NULL; *newlink = NULL; return true; } static bool dir_realloc(HTAB *hashp) { HASHSEGMENT *p; HASHSEGMENT *old_p; long new_dsize; long old_dirsize; long new_dirsize; if (hashp->hctl->max_dsize != NO_MAX_DSIZE) return false; /* Reallocate directory */ new_dsize = hashp->hctl->dsize << 1; old_dirsize = hashp->hctl->dsize * sizeof(HASHSEGMENT); new_dirsize = new_dsize * sizeof(HASHSEGMENT); old_p = hashp->dir; CurrentDynaHashCxt = hashp->hcxt; p = (HASHSEGMENT *) hashp->alloc((Size) new_dirsize); if (p != NULL) { memcpy(p, old_p, old_dirsize); MemSet(((char *) p) + old_dirsize, 0, new_dirsize - old_dirsize); hashp->dir = p; hashp->hctl->dsize = new_dsize; /* XXX assume the allocator is palloc, so we know how to free */ Assert(hashp->alloc == DynaHashAlloc); pfree(old_p); return true; } return false; } static HASHSEGMENT seg_alloc(HTAB *hashp) { HASHSEGMENT segp; CurrentDynaHashCxt = hashp->hcxt; segp = (HASHSEGMENT) hashp->alloc(sizeof(HASHBUCKET) * hashp->ssize); if (!segp) return NULL; MemSet(segp, 0, sizeof(HASHBUCKET) * hashp->ssize); return segp; } ``` ### 三、跟踪分析 测试脚本 ``` [local:/data/run/pg12]:5120 pg12@testdb=# \d t_expand; Table "public.t_expand" Column | Type | Collation | Nullable | Default --------+---------+-----------+----------+--------- id | integer | | | [local:/data/run/pg12]:5120 pg12@testdb=# select count(*) from t_expand; count --------- 2000000 (1 row) [local:/data/run/pg12]:5120 pg12@testdb=# select * from t_expand; ... ``` 启动gdb跟踪 ``` (gdb) b hash_search_with_hash_value Breakpoint 2 at 0xa790f2: file dynahash.c, line 925. (gdb) c Continuing. Breakpoint 2, hash_search_with_hash_value (hashp=0x224eac8, keyPtr=0x7fffed717700, hashvalue=2252448879, action=HASH_ENTER, foundPtr=0x7fffed7176ff) at dynahash.c:925 925 HASHHDR *hctl = hashp->hctl; --> hash控制结构体 (gdb) n 926 int freelist_idx = FREELIST_IDX(hctl, hashvalue);--> 空闲链表 (gdb) p *hctl $1 = {freeList = {{mutex = 0 '\000', nentries = 0, freeList = 0x22504d0}, {mutex = 0 '\000', nentries = 0, freeList = 0x0} <repeats 31 times>}, dsize = 256, nsegs = 1, max_bucket = 15, high_mask = 31, low_mask = 15, keysize = 20, entrysize = 72, num_partitions = 0, ffactor = 1, max_dsize = -1, ssize = 256, sshift = 8, nelem_alloc = 46} (gdb) n 949 if (action == HASH_ENTER || action == HASH_ENTER_NULL) (gdb) 956 if (!IS_PARTITIONED(hctl) && !hashp->frozen && (gdb) 957 hctl->freeList[0].nentries / (long) (hctl->max_bucket + 1) >= hctl->ffactor && --> 判断是否需要扩展 (gdb) 956 if (!IS_PARTITIONED(hctl) && !hashp->frozen && (gdb) 965 bucket = calc_bucket(hctl, hashvalue);-->计算hash桶 (gdb) step calc_bucket (hctl=0x224eb60, hash_val=2252448879) at dynahash.c:871 871 bucket = hash_val & hctl->high_mask;-->先行与high_mask(31)进行掩码运算 (gdb) n 872 if (bucket > hctl->max_bucket)-->得到的结果如何比max_bucket还大,那要跟low_mask(15)进行掩码运算 (gdb) p bucket $2 = 15 (gdb) n 875 return bucket; (gdb) l 870 871 bucket = hash_val & hctl->high_mask; 872 if (bucket > hctl->max_bucket) 873 bucket = bucket & hctl->low_mask; 874 875 return bucket; 876 } 877 878 /* 879 * hash_search -- look up key in table and perform action (gdb) n 876 } (gdb) hash_search_with_hash_value (hashp=0x224eac8, keyPtr=0x7fffed717700, hashvalue=2252448879, action=HASH_ENTER, foundPtr=0x7fffed7176ff) at dynahash.c:967 967 segment_num = bucket >> hashp->sshift;-->seg号,相当于15/256,结果为0 (gdb) 968 segment_ndx = MOD(bucket, hashp->ssize);-->seg内编号,相当于15/256取模,结果为15 (gdb) 970 segp = hashp->dir[segment_num]; (gdb) 972 if (segp == NULL) (gdb) p segment_num $3 = 0 (gdb) p segment_ndx $4 = 15 (gdb) n 975 prevBucketPtr = &segp[segment_ndx]; (gdb) 976 currBucket = *prevBucketPtr; (gdb) 981 match = hashp->match; /* save one fetch in inner loop */ (gdb) 982 keysize = hashp->keysize; /* ditto */ (gdb) 984 while (currBucket != NULL) (gdb) 997 if (foundPtr) (gdb) 998 *foundPtr = (bool) (currBucket != NULL); (gdb) 1003 switch (action) (gdb) 1047 if (currBucket != NULL) (gdb) 1051 if (hashp->frozen) (gdb) 1055 currBucket = get_hash_entry(hashp, freelist_idx); (gdb) 1056 if (currBucket == NULL) (gdb) 1073 *prevBucketPtr = currBucket; (gdb) 1074 currBucket->link = NULL; (gdb) 1077 currBucket->hashvalue = hashvalue; (gdb) 1078 hashp->keycopy(ELEMENTKEY(currBucket), keyPtr, keysize); (gdb) 1087 return (void *) ELEMENTKEY(currBucket); (gdb) 1093 } (gdb) hash_search (hashp=0x224eac8, keyPtr=0x7fffed717700, action=HASH_ENTER, foundPtr=0x7fffed7176ff) at dynahash.c:916 916 } (gdb) ``` ### 四、参考资料 N/A
