[20181207]12c bootstrap$段头都会记录在哪里.txt

来源：这里教程网时间：2026-03-03 12:42:49 作者：

[20181207]12c bootstrap$段头都会记录在哪里.txt --//oracle数据库启动需要知道sys.bootstrap$段头,一般会记录在system文件的文件头,可以通过内部视图 --//x$kcvfh.FHRDB显示,而12c呢? 先来看看11g的情况: 1. 环境: SCOTT@book> @ ver1 PORT_STRING VERSION BANNER ------------------------------ -------------- -------------------------------------------------------------------------------- x86_64/Linux 2.4.xx 11.2.0.4.0 Oracle Database 11g Enterprise Edition Release 11.2.0.4.0 - 64bit Production SYS@book> select fhrdb,fhfno,hxfnm from x$kcvfh order by 2; FHRDB FHFNO HXFNM ---------- ---------- ---------------------------------------- 4194824 1 /mnt/ramdisk/book/system01.dbf 0 2 /mnt/ramdisk/book/sysaux01.dbf 0 3 /mnt/ramdisk/book/undotbs01.dbf 0 4 /mnt/ramdisk/book/users01.dbf 0 5 /mnt/ramdisk/book/example01.dbf 0 6 /mnt/ramdisk/book/tea01.dbf 6 rows selected. --//可以发现仅仅记录在file#=1的system表空间(你可以往系统表空间里面加入数据文件,可以发现仅仅file#=1记录这个信息) --//贴一个生产系统的例子: SYS@dbcn1> select fhrdb,fhfno,hxfnm from x$kcvfh where hxfnm like '%system%' order by 2; FHRDB FHFNO HXFNM ---------- ---------- -------------------------------------------------- 4194824 1 +DATAC1/XxXX/datafile/system.308.862160493 0 29 +DATAC1/Xxxx/datafile/system01.bdf --//4194824= alter system dump datafile 1 block 520 --//通过bbed观察也可以验证上面的情况: BBED> set dba 4194824 DBA 0x00400208 (4194824 1,520) BBED> set dba 1,1 DBA 0x00400001 (4194305 1,1) BBED> p dba 1,1 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> set dba 0x00400208 DBA 0x00400208 (4194824 1,520) BBED> p dba 2,1 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00000000 --//数据文件2为空. SYS@book> select SEGMENT_NAME,HEADER_FILE,HEADER_BLOCK from dba_segments where segment_name='BOOTSTRAP$' and owner='SYS'; SEGMENT_NAME HEADER_FILE HEADER_BLOCK -------------------- ----------- ------------ BOOTSTRAP$ 1 520 --//而12c,18c呢? 基本现在12c以上都建议使用pdb. 2.12c环境: SCOTT@test01p> @ ver1 PORT_STRING VERSION BANNER CON_ID ------------------------------ -------------- -------------------------------------------------------------------------------- ---------- IBMPC/WIN_NT64-9.1.0 12.2.0.1.0 Oracle Database 12c Enterprise Edition Release 12.2.0.1.0 - 64bit Production 0 2.测试: SYS@test> SELECT rfile#,file#, CHECKPOINT_CHANGE#, CHECKPOINT_TIME,CREATION_CHANGE# , RESETLOGS_CHANGE#,status, CHECKPOINT_COUNT,fuzzy,name,tablespace_name FROM v$datafile_header ; RFILE# FILE# CHECKPOINT_CHANGE# CHECKPOINT_TIME CREATION_CHANGE# RESETLOGS_CHANGE# STATUS CHECKPOINT_COUNT FUZ NAME TABLESPACE_NAME ------ ----- ------------------ ------------------- ---------------- ----------------- ------ ---------------- --- -------------------------------------------------- ------------------- 1 1 2393063 2018-10-16 20:20:13 9 1 ONLINE 92 YES D:\APP\ORACLE\ORADATA\TEST\SYSTEM01.DBF SYSTEM 1 2 1102125 2018-10-06 23:24:44 227 1 ONLINE 37 NO D:\APP\ORACLE\ORADATA\TEST\PDBSEED\SYSTEM01.DBF SYSTEM 3 3 2393063 2018-10-16 20:20:13 4748 1 ONLINE 92 YES D:\APP\ORACLE\ORADATA\TEST\SYSAUX01.DBF SYSAUX 4 4 1102125 2018-10-06 23:24:44 4762 1 ONLINE 37 NO D:\APP\ORACLE\ORADATA\TEST\PDBSEED\SYSAUX01.DBF SYSAUX 5 5 2393063 2018-10-16 20:20:13 6090 1 ONLINE 92 YES D:\APP\ORACLE\ORADATA\TEST\UNDOTBS01.DBF UNDOTBS1 6 6 1102125 2018-10-06 23:24:44 6212 1 ONLINE 37 NO D:\APP\ORACLE\ORADATA\TEST\PDBSEED\UNDOTBS01.DBF UNDOTBS1 7 7 2393063 2018-10-16 20:20:13 28597 1 ONLINE 91 YES D:\APP\ORACLE\ORADATA\TEST\USERS01.DBF USERS 1 8 2394047 2018-10-16 20:22:11 1103550 1 ONLINE 71 YES D:\APP\ORACLE\ORADATA\TEST\TEST01P\SYSTEM01.DBF SYSTEM 4 9 2394047 2018-10-16 20:22:11 1103553 1 ONLINE 71 YES D:\APP\ORACLE\ORADATA\TEST\TEST01P\SYSAUX01.DBF SYSAUX 6 10 2394047 2018-10-16 20:22:11 1103555 1 ONLINE 71 YES D:\APP\ORACLE\ORADATA\TEST\TEST01P\UNDOTBS01.DBF UNDOTBS1 11 11 2394047 2018-10-16 20:22:11 1105613 1 ONLINE 70 YES D:\APP\ORACLE\ORADATA\TEST\TEST01P\USERS01.DBF USERS 11 rows selected. --//file#=1,2,8属于system表空间. SYS@test> select fhrdb,fhfno from x$kcvfh order by 2; FHRDB FHFNO ------------ ------------ 4194824 1 4194824 2 0 3 4194824 4 0 5 4194824 6 0 7 4194824 8 4194824 9 4194824 10 4194824 11 11 rows selected. --//而12c呢,PDB的数据文件全部有,file#=4对应PDB=PDBSEED的SYSAUX表空间的数据文件. --//file#=6对应PDB=PDBSEED的UNDOTBS1表空间数据文件. --//也就是file# 3,5,7没有,这些都是cdb下的数据文件. SYS@test> @ dfb10 4194824 RFILE# BLOCK# ------------ ------------ 1 520 TEXT ------------------------------------------------------------ alter system dump datafile 1 block 520 ; 3.使用bbed验证看看: --//windows 下 bbed无法识别数据文件的OS块头,存在1个块的偏移,看数据文件头块要+1. BBED> p dba 1,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 2,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 4,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 6,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 8,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 9,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 10,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> p dba 11,2 kcvfh.kcvfhrdb ub4 kcvfhrdb @96 0x00400208 BBED> set dba 0x00400208 DBA 0x00400208 (4194824 1,520) --//都是0x00400208,对应dba就是1,520,也就是bootstrap$的位置. --//在cdb下查看: SYS@test> select header_file,header_block from dba_segments where owner='SYS' and segment_name='BOOTSTRAP$'; HEADER_FILE HEADER_BLOCK ------------ ------------ 1 520 --//在PDB=test01p下查看: SCOTT@test01p> select header_file,header_block from dba_segments where owner='SYS' and segment_name='BOOTSTRAP$'; HEADER_FILE HEADER_BLOCK ----------- ------------ 8 520 --//12c为什么这样设计,搞不懂. 4.再看看18c的情况: SYS@orclcdb> select banner from v$version where rownum<=1; BANNER -------------------------------------------------------------------------------- Oracle Database 18c Enterprise Edition Release 18.0.0.0.0 - Production SYS@orclcdb> column name format a80 SYS@orclcdb> SELECT rfile#,file#, CHECKPOINT_CHANGE#, CHECKPOINT_TIME,CREATION_CHANGE# , RESETLOGS_CHANGE#,status, CHECKPOINT_COUNT,fuzzy,name,tablespace_name FROM v$datafile_header where TABLESPACE_NAME='SYSTEM'; RFILE# FILE# CHECKPOINT_CHANGE# CHECKPOINT_TIME CREATION_CHANGE# RESETLOGS_CHANGE# STATUS CHECKPOINT_COUNT FUZ NAME TABLESPACE_NAME ---------- ---------- ------------------ ------------------- ---------------- ----------------- ------ ---------------- --- -------------------------------------------------------------------------------- -------------------- 1 1 1342732614 2018-12-07 07:07:04 8 1477662 ONLINE 2471 YES +DATA/ORCLCDB/DATAFILE/system.273.985030351 SYSTEM 1 5 1557588 2018-08-24 19:45:15 1508071 1477662 ONLINE 11 NO +DATA/ORCLCDB/64A52F53A7693286E053CDA9E80AED76/DATAFILE/system.270.985030667 SYSTEM 1 38 1342732614 2018-12-07 07:07:04 1314973853 1477662 ONLINE 907 YES +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/system.275.985549575 SYSTEM SYS@orclcdb> column HXFNM format a82 SYS@orclcdb> select fhrdb,fhfno,hxfnm from x$kcvfh where FHRDB=4194824; FHRDB FHFNO HXFNM ---------- ---------- ---------------------------------------------------------------------------------- 4194824 1 +DATA/ORCLCDB/DATAFILE/system.273.985030351 4194824 5 +DATA/ORCLCDB/64A52F53A7693286E053CDA9E80AED76/DATAFILE/system.270.985030667 4194824 6 +DATA/ORCLCDB/64A52F53A7693286E053CDA9E80AED76/DATAFILE/sysaux.269.985030667 4194824 8 +DATA/ORCLCDB/64A52F53A7693286E053CDA9E80AED76/DATAFILE/undotbs1.267.985030667 4194824 38 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/system.275.985549575 4194824 39 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/sysaux.278.985549575 4194824 40 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/undotbs1.277.985549575 4194824 41 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/users.276.985549575 4194824 42 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy.279.985551679 4194824 43 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_05.281.985551715 4194824 44 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_06.280.985551731 4194824 45 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_07.282.985551735 4194824 46 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_08.283.985551737 4194824 47 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_09.284.985551757 4194824 48 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_10.285.985551797 4194824 49 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_11.289.985551845 4194824 50 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_12.290.985551895 4194824 51 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_13.291.985551949 4194824 52 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_14.292.985552009 4194824 53 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_15.293.985552077 4194824 54 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_16.294.985552149 4194824 55 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_17.295.985552231 4194824 56 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_18.296.985552313 4194824 57 +DATA/ORCLCDB/74A69DC145F5662BE0558253DD747177/DATAFILE/xx_yyyy_indx.297.985553863 24 rows selected. SYS@orclcdb> select fhrdb,fhfno,hxfnm from x$kcvfh where FHRDB<>4194824; FHRDB FHFNO HXFNM ---------- ---------- ---------------------------------------------------------------------------------- 0 3 +DATA/ORCLCDB/DATAFILE/sysaux.259.985030395 0 4 +DATA/ORCLCDB/DATAFILE/undotbs1.271.985030421 0 7 +DATA/ORCLCDB/DATAFILE/users.260.985030421 --//可以发现仅仅cdb下的除了FHFNO=1,其它文件头没有写入root_rdba信息,剩下的数据文件头都写入root_rdba信息.
