Linux7.4 安装oracle 19C RAC

##安装rpm

yum -y install bc gcc gcc-c++  binutils  make gdb cmake  glibc ksh elfutils-libelf elfutils-libelf-devel fontconfig-devel glibc-devel libaio libaio-devel libXrender libXrender-devel libX11 libXau sysstat libXi libXtst libgcc librdmacm-devel libstdc++ libstdc++-devel libxcb net-tools nfs-utils compat-libcap1 compat-libstdc++  smartmontools  targetcli python python-configshell python-rtslib python-six  unixODBC unixODBC-devel
ls -l compat* elfutils* | awk -v rpmpackage="" '{rpmpackage=$NF" "rpmpackage}END{print "yum -y localinstall "rpmpackage}' | bash

##创建要用户和组

groupadd -g 11001 oinstall
groupadd -g 11002 dba
groupadd -g 11003 oper
groupadd -g 11004 backupdba
groupadd -g 11005 dgdba
groupadd -g 11006 kmdba
groupadd -g 11007 asmdba
groupadd -g 11008 asmoper
groupadd -g 11009 asmadmin
groupadd -g 11010 racdba
  useradd -u 11011 -g oinstall -G dba,asmdba,backupdba,dgdba,kmdba,racdba,oper oracle
useradd -u 11012 -g oinstall -G asmadmin,asmdba,asmoper,dba grid
[root@ray21 yum.repos.d]# echo oracle | passwd --stdin oracle
Changing password for user oracle.
passwd: all authentication tokens updated successfully.
[root@ray21 yum.repos.d]# echo oracle | passwd --stdin grid
Changing password for user grid.
passwd: all authentication tokens updated successfully.

##编辑hosts文件

#public ip
192.168.56.21 ray21
192.168.56.22 ray22
#private ip
192.168.57.21 ray21-priv
192.168.57.22 ray22-priv
#vip
192.168.56.23 ray21-vip
192.168.56.24 ray22-vip
#scan ip
192.168.56.25 racscan

##时间设置

##设置时区
[root@ray21 yum.repos.d]# timedatectl list-timezones |grep Shanghai
Asia/Shanghai
[root@ray21 yum.repos.d]# timedatectl set-timezone Asia/Shanghai
[root@ray22 ~]# systemctl stop ntpd.service
[root@ray22 ~]# systemctl disable ntpd.service
[root@ray22 ~]# mv /etc/ntp.conf /etc/ntp.conf.orig
[root@ray22 ~]# systemctl status ntpd

##创建目录

mkdir -p /u01/app/19.0.0/grid
mkdir -p /u01/app/grid
mkdir -p /u01/app/oracle
mkdir -p /u01/app/oracle/product/19.0.0/db_1
chown -R grid:oinstall /u01/app/grid
chown -R grid:oinstall /u01/app/19.0.0/grid
chown -R oracle:oinstall /u01/app/oracle
chmod -R 775 /u01/

##编辑/etc/security/limits.d/20-nproc.conf

vi /etc/security/limits.d/20-nproc.conf
#注释这行* soft nproc 1024
#增加下面一行
* - nproc 16384

##编辑limits.conf

vi /etc/security/limits.conf
grid  soft  nproc 16384
grid  hard  nproc 16384
grid  soft  nofile 1024
grid  hard  nofile 65536
grid  soft  stack 10240
grid  hard  stack 32768
oracle soft nproc 16384
oracle hard nproc 16384
oracle soft nofile 1024
oracle hard nofile 65536
oracle soft stack  10240
oracle hard stack  32768
oracle hard memlock 4194304
oracle soft memlock 4194304
##memlock这个值还是应该比内存配置略小，也就是要配置的足够大。单位：k
##4194304 表示4G

##配置pam

[root@ray21 ~]# vi /etc/pam.d/login
#ORACLE SETTING
session required pam_limits.so

##配置sysctl文件

/sbin/sysctl -a | grep shm
vi /etc/sysctl.conf
fs.aio-max-nr = 1048576
fs.file-max = 6815744
kernel.shmall = 18446744073692774399
kernel.shmmax = 18446744073692774399
kernel.shmmni = 4096
kernel.sem = 250 32000 100 128
net.ipv4.ip_local_port_range = 9000 65500
net.core.rmem_default = 262144
net.core.rmem_max = 4194304
net.core.wmem_default = 262144
net.core.wmem_max = 1048576
sysctl -p

##停止avahi-daemon服务

[root@ray22 ~]# systemctl disable avahi-daemon.socket
Removed symlink /etc/systemd/system/sockets.target.wants/avahi-daemon.socket.
[root@ray22 ~]# systemctl disable avahi-daemon.service
Removed symlink /etc/systemd/system/multi-user.target.wants/avahi-daemon.service.
Removed symlink /etc/systemd/system/dbus-org.freedesktop.Avahi.service.
[root@ray22 ~]# ps -ef|grep avahi-daemon
avahi      704     1  0 10:24 ?        00:00:00 avahi-daemon: running [ray22.local]
avahi      771   704  0 10:24 ?        00:00:00 avahi-daemon: chroot helper
root     15225  1671  0 13:59 pts/0    00:00:00 grep --color=auto avahi-daemon
[root@ray22 ~]# kill -9 704 771

##编辑network文件

[root@ray21 ~]# vi /etc/sysconfig/network
NOZEROCONF=yes

##编辑bash_profile文件

节点一
Su - grid
ORACLE_SID=+ASM1; export ORACLE_SID
#ORACLE_TERM=xterm; export ORACLE_TERM
ORACLE_BASE=/u01/app/grid; export ORACLE_BASE
ORACLE_HOME=/u01/app/19.0.0/grid; export ORACLE_HOME
NLS_DATE_FORMAT="yyyy-mm-dd HH24:MI:SS"; export NLS_DATE_FORMAT
PATH=.:$PATH:$HOME/bin:$ORACLE_HOME/bin
export LD_LIBRARY_PATH=$ORACLE_HOME/lib:/lib:/usr/lib
export CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib
Su - oracle
export ORACLE_BASE=/u01/app/oracle
export ORACLE_HOME=$ORACLE_BASE/product/19.0.0/db_1
export ORACLE_SID=RACDB1
PATH=$ORACLE_HOME/bin:$PATH
export LD_LIBRARY_PATH=$ORACLE_HOME/bin:/bin:/usr/bin:/usr/local/bin
export CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib
节点二
Su - grid
ORACLE_SID=+ASM2; export ORACLE_SID
#ORACLE_TERM=xterm; export ORACLE_TERM
ORACLE_BASE=/u01/app/grid; export ORACLE_BASE
ORACLE_HOME=/u01/app/19.0.0/grid; export ORACLE_HOME
NLS_DATE_FORMAT="yyyy-mm-dd HH24:MI:SS"; export NLS_DATE_FORMAT
PATH=.:$PATH:$HOME/bin:$ORACLE_HOME/bin
export LD_LIBRARY_PATH=$ORACLE_HOME/lib:/lib:/usr/lib
export CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib
Su - oracle
export ORACLE_BASE=/u01/app/oracle
export ORACLE_HOME=$ORACLE_BASE/product/19.0.0/db_1
export ORACLE_SID=RACDB2
PATH=$ORACLE_HOME/bin:$PATH
export LD_LIBRARY_PATH=$ORACLE_HOME/bin:/bin:/usr/bin:/usr/local/bin
export CLASSPATH=$ORACLE_HOME/JRE:$ORACLE_HOME/jlib:$ORACLE_HOME/rdbms/jlib

##编辑共享磁盘

[root@ray21 ~]# /usr/lib/udev/scsi_id -g -u -d /dev/sdb
1ATA_VBOX_HARDDISK_VBe5a06cf8-14a27d28
[root@ray21 ~]# /usr/lib/udev/scsi_id -g -u -d /dev/sdc
1ATA_VBOX_HARDDISK_VB7cc0c900-27b2606d
vi /etc/udev/rules.d/99-oracle-asmdevices.rules
KERNEL=="sdb", SUBSYSTEM=="block", PROGRAM=="/usr/lib/udev/scsi_id -g -u -d /dev/$name",RESULT=="1ATA_VBOX_HARDDISK_VBe5a06cf8-14a27d28",  OWNER="grid", GROUP="asmadmin", MODE="0660"
KERNEL=="sdc", SUBSYSTEM=="block", PROGRAM=="/usr/lib/udev/scsi_id -g -u -d /dev/$name",RESULT=="1ATA_VBOX_HARDDISK_VB7cc0c900-27b2606d",  OWNER="grid", GROUP="asmadmin", MODE="0660"
#重启服务
systemctl restart systemd-udev-trigger.service
或 重新加载udev
udevadm control --reload-rules
udevadm trigger
##验证权限和属组
ls -Ll /dev/mapper/*
ls -Ll /dev/oraasm-*
ls -Ll /dev/dm-*

#多路径配置
#/etc/multipath.conf
multipaths {
        multipath {
                wwid 36006048cd70c3e37a4a85c04d0c79c6d
                alias data1
        }
        multipath {
                wwid 36006048cb82e28ed3701a9e1eecb820a
                alias crs1
         }
         multipath {
                 wwid 3600601606a003a001eebdf56d80e0b2f
                 alias data2
         }
         multipath {
                 wwid 3600601606a003a004aebdf56fce34966
                 alias data3
         }
}
#配置udev
cd /dev/mapper
for i in `ls mpath*`; do printf "%s %s\n" "$i" "$(udevadm info --query=all --name=/dev/mapper/$i |grep -i dm_uuid)"; done
data1 E: DM_UUID=mpath-36006048cd70c3e37a4a85c04d0c79c6d
crs1 E: DM_UUID=mpath-36006048cb82e28ed3701a9e1eecb820a
data2 E: DM_UUID=mpath-3600601606a003a001eebdf56d80e0b2f
data3 E: DM_UUID=mpath-3600601606a003a004aebdf56fce34966
[root@rac1 ~]# vi /etc/udev/rules.d/99-oracle-asmdevices.rules
KERNEL=="dm-*",ENV{DM_UUID}=="mpath-36006048cd70c3e37a4a85c04d0c79c6d",SYMLINK+="oraasm-$env{DM_NAME}",OWNER="grid",GROUP="asmadmin",MODE="0660"
KERNEL=="dm-*",ENV{DM_UUID}=="mpath-36006048cb82e28ed3701a9e1eecb820a",SYMLINK+="oraasm-$env{DM_NAME}",OWNER="grid",GROUP="asmadmin",MODE="0660"
KERNEL=="dm-*",ENV{DM_UUID}=="mpath-3600601606a003a001eebdf56d80e0b2f",SYMLINK+="oraasm-$env{DM_NAME}",OWNER="grid",GROUP="asmadmin",MODE="0660"
KERNEL=="dm-*",ENV{DM_UUID}=="mpath-3600601606a003a004aebdf56fce34966",SYMLINK+="oraasm-$env{DM_NAME}",OWNER="grid",GROUP="asmadmin",MODE="0660"
#重启udev服务
systemctl restart systemd-udev-trigger.service
##验证权限和属组
ls -Ll /dev/mapper/*
ls -Ll /dev/oraasm-*
ls -Ll /dev/dm-*

##配置grid互信

grid:
cd /home/grid
mkdir ~/.ssh
chmod 700 ~/.ssh
ssh-keygen -t rsa
ssh-keygen -t dsa
cat ~/.ssh/id_rsa.pub >>~/.ssh/authorized_keys
cat ~/.ssh/id_dsa.pub >>~/.ssh/authorized_keys
ssh ray22 cat ~/.ssh/id_rsa.pub >>~/.ssh/authorized_keys
ssh ray22 cat ~/.ssh/id_dsa.pub >>~/.ssh/authorized_keys
scp ~/.ssh/authorized_keys ray22:~/.ssh/authorized_keys
#验证
ssh ray22 date;ssh ray21 date;ssh ray22-priv date;ssh ray21-priv date

##解压grid

[grid@ray21 ~]$ unzip -d /u01/app/19.0.0/grid/ LINUX.X64_193000_grid_home.zip

##安装cvuqdisk

[root@ray21 ~]# rpm -ivh /u01/app/19.0.0/grid/cv/rpm/cvuqdisk-1.0.10-1.rpm
Preparing...                          ################################# [100%]
Using default group oinstall to install package
Updating / installing...
   1:cvuqdisk-1.0.10-1                ################################# [100%]

##安装前检查

./runcluvfy.sh stage -pre crsinst -n ray21,ray22 -fixup -verbose >> check.txt

##安装grid

[grid@ray21 grid]$ ./gridSetup.sh

cd /home/oracle
mkdir ~/.ssh
chmod 700 ~/.ssh
ssh-keygen -t rsa
ssh-keygen -t dsa
cat ~/.ssh/id_rsa.pub >>~/.ssh/authorized_keys
cat ~/.ssh/id_dsa.pub >>~/.ssh/authorized_keys
ssh ray22 cat ~/.ssh/id_rsa.pub >>~/.ssh/authorized_keys
ssh ray22 cat ~/.ssh/id_dsa.pub >>~/.ssh/authorized_keys
scp ~/.ssh/authorized_keys ray22:~/.ssh/authorized_keys
#验证
ssh ray22 date;ssh ray21 date;ssh ray22-priv date;ssh ray21-priv date

[oracle@ray21 ~]$ unzip LINUX.X64_193000_db_home.zip -d /u01/app/oracle/product/19.0.0/db_1/

[oracle@ray21 db_1]$ ./runInstaller
