xbbed一键读取ASM block到文件系统

1. 目标说明

    xbbed主要实现一键读取asm数据块到文件系统或更新文件系统数据块到asm。
    下载方式：关注公众号“xaoug”，回复 “x_onekey”。

2. Oracle sudo权限设置

--root用户执行grep 'oracle' /etc/sudoers
echo "oracle  ALL=(ALL)       NOPASSWD: ALL" >>/etc/sudoers
grep 'oracle' /etc/sudoers
su - oracle
sudo su - grid -c pwd

3. 测试表创建

drop table hsql.t1 purge;create table hsql.t1(c1 char(10));insert into hsql.t1 values('enmo');commit;alter system flush buffer_cache;select dbms_rowid.rowid_object(rowid) object_id,
dbms_rowid.rowid_relative_fno(rowid) file_id,
dbms_rowid.rowid_block_number(rowid) block_id,
dbms_rowid.rowid_row_number(rowid) row_number,* from hsql.t1;
 OBJECT_ID    FILE_ID   BLOCK_ID ROW_NUMBER C1---------- ---------- ---------- ---------- ------------------------------
     87925          4        182          0 enmo

4. cp asm block to os

[oracle@snyxdb1 x_recovery]$ sh x_reco.sh
--------------------------------------------------------------------------------
|**********************WELCOME: x_rec for Oracle*******************************|
|1). install_bbed: bbed install one key                                        |
|2). xbbed: cp asm block to os block or reverse.                               |
|3). exit: quit the x_rec                                                      |
|*****************if you need any help contact my wechat: xidoublestar*********|
--------------------------------------------------------------------------------
pls,input operation name:xbbed
********************************WELCOM XBBED********************************
|method:                                                                   |
|1) get dba a,b <-- cp file#: a,blk#: b from asm to /tmp/xbbed/a_b.dd      |
|2) save dba a,b <-- cp /tmp/xbbed/a_b.dd to asm                           |
|3) exit                                                                   |
****************************************************************************
xbbed>get dba 4,182**********get dba 4,182**********
block_id_in_datafile: 182file_number: 4filesystem_filename: /tmp/xbbed/4_182.dd
asm_datafile_name: +OCR_VOTE/epmsn/datafile/users.259.1076411313PL/SQL procedure successfully completed.
xbbed>

5. 使用bbed修改数据内容

[oracle@snyxdb1 bbed]$ cat listfile.txt
1 /tmp/xbbed/4_182.dd
[oracle@snyxdb1 bbed]$ sh l_bbed.sh
BBED: Release 2.0.0.0.0 - Limited Production on Mon Nov 1 10:27:13 2021Copyright (c) 1982, 2011, Oracle and/or its affiliates.  All rights reserved.
************* !!! For Oracle Internal Use only !!! ***************
BBED> set dba 1,1
        DBA             0x00400001 (4194305 1,1)
BBED>
BBED> p *kdbr[0]
rowdata[0]----------ub1 rowdata[0]                              @8174     0x2cBBED> x /rccc
rowdata[0]                                  @8174    ----------flag@8174: 0x2c (KDRHFL, KDRHFF, KDRHFH)lock@8175: 0x01cols@8176:    1col   0[10] @8177: enmo
BBED> d offset 8177 count 16
 File: /tmp/xbbed/4_182.dd (1) Block: 1                Offsets: 8177 to 8191           Dba:0x00400001------------------------------------------------------------------------
 0a656e6d 6f202020 20202001 065139
 <32 bytes per line>
BBED> m /x 65 offset 8182Warning: contents of previous BIFILE will be lost. Proceed? (Y/N) y File: /tmp/xbbed/4_182.dd (1) Block: 1                Offsets: 8182 to 8191           Dba:0x00400001------------------------------------------------------------------------
 65202020 20200106 5139
 <32 bytes per line>
BBED> sum applyCheck value for File 1, Block 1:current = 0x233d, required = 0x233dBBED> d offset 8177 count 16
 File: /tmp/xbbed/4_182.dd (1) Block: 1                Offsets: 8177 to 8191           Dba:0x00400001------------------------------------------------------------------------
 0a656e6d 6f652020 20202001 065139
 <32 bytes per line>
BBED> p *kdbr[0]
rowdata[0]----------ub1 rowdata[0]                              @8174     0x2cBBED> x /rccc
rowdata[0]                                  @8174    ----------flag@8174: 0x2c (KDRHFL, KDRHFF, KDRHFH)lock@8175: 0x01cols@8176:    1col   0[10] @8177: enmoe
BBED>

5. cp os block to asm

xbbed>save dba 4,182
**********save dba 4,182**********
file_with_patched_block: /tmp/xbbed/4_182.dd
file_to_patch_in_ASM: +OCR_VOTE/epmsn/datafile/users.259.1076411313
v_offstart: 182
PL/SQL procedure successfully completed.
xbbed>

6. 结果检查

[oracle@snyxdb1 ~]$ sqlplus / as sysdba
SQL*Plus: Release 11.2.0.4.0 Production on Mon Nov 1 10:29:17 2021Copyright (c) 1982, 2013, Oracle.  All rights reserved.
Connected to:Oracle Database 11g Enterprise Edition Release 11.2.0.4.0 - 64bit ProductionWith the Partitioning, Automatic Storage Management, OLAP, Data Miningand Real Application Testing optionsSQL> alter system flush buffer_cache;
System altered.
SQL> select * from hsql.t1;
C1
------------------------------
enmoe
SQL>

7. 重置Oracle sudo权限设置

grep 'oracle' /etc/sudoers
sed -ri 's/^oracle/#oracle/' /etc/sudoers
grep 'oracle' /etc/sudoers
su - oracle
sudo su - grid -c pwd

欢迎关注公众号交流沟通“xaoug”
